ALLOY:- PHOSPHORUS BRONZE (GRADE-5)
STANDARD :- IS: 28-1985
| CHEMICAL COMPOSITION |
MIN (%) |
MAX(%) |
| Copper (cu) |
BALANCE |
| Tin (Sn) |
11.00 |
13.10 |
| Lead (Pb) |
- |
0.50 |
| Zinc (Zn) |
- |
0.30 |
| Phosphorus (P) |
0.15 |
- |
| Nickle (Ni) |
- |
0.50 |
| Iron (Fe) |
- |
0.15 |
| Antimony (Sb) |
- |
- |
| Aluminium (Al) |
- |
0.01 |
| Silicon (Si) |
- |
0.02 |
| MECHANICAL PROPERTIES |
Minimum Values |
| Molding Process |
Sand Casting |
Continuous Casting |
| Tensile Strength Rm (MPa) |
270 |
310 |
| 0,2% Proof Strength Rp0,2 (MPa) |
130 |
150 |
| Elongation (%) |
5 |
6 |
| Hardness |
80 |
90 |
| EQUIVALENT INTERNATIONAL STANDARD |
| STANDARD |
ALLOY |
| BS 1400 |
PB 2 |
| DIN 1705 |
CuSn12 |
| EN 1982 |
CuSn12-C, CB483K |
| ASTM B505 |
C90700 |
| JIS H5121 |
CAC 503C |
| TECHNICAL CHARACTERISTIC |
| Anti-friction properties make it a much-in-demand alloy |
| Hard wearing bronze containing a small amount of phosphorus |
| Phosphorus increases wear resistance |
| suitable for bearings with high loads and pressure requirements |
